Available Capacities
| 22.0 Bar Maximum Allowable Working Pressure Tank |
24,500 ltr |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
24,600 ltr |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
24,500 ltr |
Maximum Gross Weights
| 22.0 Bar Maximum Allowable Working Pressure Tank |
35,000 kgs |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
36,000 kgs |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
36,000 kgs |
Tare Weights
| 22.0 Bar Maximum Allowable Working Pressure Tank |
7,350 kgs |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
7,670 kgs |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
8,950 kgs |
Test Pressure
| 22.0 Bar Maximum Allowable Working Pressure Tank |
28.6 bar (Periodic) 36.7 bar (Initial – MITI) |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
36.3 bar (Periodic) 46.0 bar (Initial – MITI) |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
45.9 bar (Periodic) 57.6 bar (Initial – MITI) |
Ambient Temperature Range
| 22.0 Bar Maximum Allowable Working Pressure Tank |
-40°C to +55°C |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
-50°C to +55°C |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
-40°C to +41.6°C/55°C |
Maximum Cargo Temperature
| 22.0 Bar Maximum Allowable Working Pressure Tank |
+55°C |
| 27.5 Bar Maximum Allowable Working Pressure Tank |
+55°C |
| 34.4 Bar Maximum Allowable Working Pressure Tank |
+55°C |
